Specifications
Standard
IEEE 802.11n, IEEE 802.11g, IEEE 802.11b
IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE802.3x
Interface
1 x RJ-45 WAN port
1 x RJ-45 LAN port
1 x WPS/Reset button
Security
64/128-bit WEP, WPA, WPA2
Receiver Sensitivity
802.11b: -86dBm, 802.11g: -71dBm, 802.11n: -67dBm
Channel
USA 11, Europe 13
Transmit Power
802.11b 17dBm, 802.11g 15dBm, 802.11n 20MHz and
802.11n 40MHz 13dBm
LED Indicator
1 x Power/Status, 1 x WPS, 1 x WLAN, 1 x LAN, 1 x WAN
Antenna Type
2 x Internal PIFA antenna
Humidity & Temperature 10 ~ 90% RH, non-condensing, 0° ~ 40°C
Dimensions
56.0 x 42.0 x 13.5 mm
Power
DC 5V/0.6A (microUSB Connector)
Weight
Approx. 23 grams
Certification
FCC, NCC, CE, VCCI
