Locating the parts and controls

Refer to the pages indicated in parentheses () for details.

Display unit

CHARGE lamp (41)

POWER/POWER SAVING
lamp (23, 38)
POWER switch (23, 30)

PC-VIDEO switch

(15 to 19,31)

S VIDEO connector (19)

DC IN connector

(20,41)

Ventilation openings (46)

PUSH DISPLAY jog dial (23, 37)

MENU button (37)

SCREEN switch (34)

SEE-THROUGH control (34)

ВАТТ RELEASE button (41)

BRIGHT control (32)

VOL control (32)

AUDIO/VIDEO connector (18, 19

14-
