Specifications
video recording system
Two Rotary heads, Helical
scanning FM system
Audio recording system
Rotary head, FM system
NTSC color, EIA standards
8 mm video format cassette
SP mode: Approx. 1.43 cm (19/32
inches) /sec
LP mode: Approx. 0.72 cm (5/16
inches) /sec (playback only)
SP mode: 2 hours (P6-120)
SP mode: 2 hours (P6-120)
LP mode: 4 hours (P6-120)
Fastforward/rewind time
Approx. 6.5 min. (P6-120)
CCD (Charge Coupled Device)
Electronic viewfinder
(monochrome)
Combined 10 x power zoom lens
f-6.2 to 62 mm (1/4 to 2 15/32
inches)
F 1.8 to 2.2
Filter diameter 37 mm (1 1/2
inches)
TTL autofocus system
Color temperature
Auto, HOLD, ^ (indoors) 3,200 K,
^ (outdoors) 5,800 K
Minimum illumination
4 lux (F 1.8)
Illumination range
4 lux to 100,000 lux
Recommended illumination
More than 100 lux
Video signal
Usable cassette
Tape speed
Recording time
Playback time
Image device
Viewfinder
Lens
Input and output connectors
Video input/output
Selectable with IN/OUT selector
Phono jack, 1 Vp-p, 75 ohms,
unbalanced, sync negative
Audio input/output
Selectable with IN/OUT selector
Phono jacks.
Input: -7.5 dBs, input impedance
more than 47 kilohms
Output: -7.5 dBs, (at output
impedance 47 kilohms) impedance
less than 2.2 kilohms
RFU DC OUT Special mini-jack, DC 5 V
Earphone jack Minijack, impedance 8 ohms
Remote jack Stereo mini-minijack (0 2.5)
MIC jack Mini-jack, -66 dBs low impedance
with 2.5 to 3 V DC, output
impedance 6.8 kilohms (0 3.5)
General
Power requirements
On battery mounting surface
6.0 V (battery pack)
7.5 V (AC power adaptor)
Power consumption
6.0 W (camera recording) including
the viewfinder
Installation Vertically, Horizontally
Operating temperature
0 ®C to 40 °C (32 °F to 104 “F)
Storage temperature
-20 ®C to +60 “C
(14 ®F to 140 ®F)
Dimendions Approx. 127 x 122 x 185 mm
(w/h/d)
(5 x 47/8 x7 3/8 inches)
Weight Approx. 950 g (2 lb 2 oz)
excluding the battery pack, lithium
battery and cassette
Approx. 1125g (2 lb 7 oz) including
the battery pack NP-5S, lithium
battry and cassette P6-120
Microphone Electret condenser microphone,
monaural type
Supplied accessories
See page 5.
Design and specifications are subject to change
without notice.
Chapter 4: Additional Information
71
