Installing the Battery Pack
When you have finished charging the iiattery, instaii the battery pack as foliows:
m
1 Lift up the viewfinder.
2 Aiign the right side of the battery pack with the line on the camcorder.
3 Slide the battery pack to the right.
Note
Make sure the battery is securely installed so that it does not fall. If the battery
is not installed properly, the camcorder will not record accurately.
A fully charged battery pack lasts for:
Type of
battery pack
NP-56
(supplied)
NP-77HD NP-77H NP-77 NP-66H NP-55H
Battery life 50 130 130 110 90 60
(approx, minutes, continuous recording when used indoors)
When the battery power becomes weak, the ds? indication and red lamp flash
inside the viewfinder and the dg indication flashes in the display window. Wait
until they flash rapidly, then replace the battery pack with a fully charged one.
Inside the'vlewfinder
.'ipi
In the display window
To remove the Press ВАТТ in the direction of arrow (1), and at the same time, slide out the
battery pack battery pack to the left (2).
Chapter 1: Getting Started 7
