INLET PIPING (Hose fitted)
CAUTION
■ Arrange the parts to be positioned free from interference with the hoses, so there's no tension.
■ Apply a small amount of engine oil to lubricate the tapered surface of the AN screw.
Failure to do so can cause fuel leaks if the tapered surface is scratched.
① Temporarily fit the inlet hose.
90°
Hose A
Fuel Pressure Gauge Adapter
Straight
3 Way Joint
Straight
Hose C
Positioned below
Filter
Hose A
90°
Econ-O
90°
