Assembly configuration, Caution – Tomei Powered MAIN STUD LADDER SET User Manual
Page 7
ASSEMBLY CONFIGURATION
Cylinder Block
Main Stud
※Refer to instructions
Crankshaft
Main Bearing Cap
Crank Cap Ladder
※Refer to instructions
Washer
Crank Side
7
Oil Pan Baffle
※Crank Cap Ladder
Refer to instructions
12 Hex Nut
Oil Pan
※Crank Cap Ladder
Refer to instructions
CAUTION
■ The above mentioned information relates to the torque tightening of the main studs.
Please use the Toyota Workshop Service manual for other information's about bearing
selections, mating, assembly and overall guidelines. (Engine repair workshop service manual)
When using this product, the clamping force on the crankshaft bearing will be significantly higher.
Please select the right bearing to suit the new setup. Adequate clearance will not be possible
without the correct bearing selections to suit the new setup.
Chamfered
7
