Accessing LM
Page 5-2
5.1.1 Dumb Terminal Configuration
Configure the LM console according to the parameter settings defined in
Table 5-1. On VT100/200/300 series terminals, press F3 to access the Setup
Directory. For setup parameters not listed in the following table, any
selection should be acceptable. Refer to terminal’s manual for more
instructions if necessary.
Table 5-1. Setup Requirements for LM Console
Menu Parameter Setting
Display Setup: Columns 80 Columns
Controls Interpret controls
Auto wrap No Auto wrap
Text Cursor No Cursor
General Setup: Mode VT100, 7 bit control
Cursor keys Normal cursor keys
Communications
Setup: Transmit (all values from 2400 to
19,200 accepted)
Receive Receive = transmit
Bits, parity 8 Bits, no parity
Stop Bit 1 Stop Bit
Local Echo No Local Echo
Port Data Leads Only
Auto Answerback No Auto Answerback
Keyboard Setup: Keys Typewriter keys
Margin bell Margin bell
Warning bell Warning bell
Auto Answerback No Auto Answerback
