Using Your Computer
Adamo XPS™ Service Manual
Left View Features
Right View Features
Front View Features
Power Light Status
This section provides information about the features available on your Adamo XPS computer.
Left View Features
Right View Features
Front View Features
1 USB 2.0 connector — Connects to USB devices, such as a mouse, keyboard, printer,
external drive, or MP3 player.
2 DisplayPort connector — Connects to external monitors, TVs, or projectors.
1 Audio out/Headphone connector — Connects to a pair of headphones or to a powered
speaker or sound system.
2 USB 2.0 connector — Connects to USB devices, such as a mouse, keyboard, printer,
external drive, or MP3 player.
3 AC adapter connector — Connects to the AC adapter to power the computer and charge
the computer battery.
