2. Align the notch in the memory module with the tab in the memory module connector.
3. Slide the module firmly into the slot at a 45-degree angle, and press the other end of the module down until it clicks into place. If you do not hear the
click, remove the module and reinstall it.
4. Replace the palm rest assembly (see Replacing the Palm Rest Assembly ).
5. Replace the computer battery (see Replacing the Computer Battery ).
6. Turn on the computer.
As the computer boots, it detects the memory and automatically updates the system configuration information.
To confirm the amount of memory installed in the computer,
Click Start ® Control Panel® System and Security® System.
Back to Contents Page
NOTE: If the memory module is not installed properly, the computer may not boot.
CAUTION: Before turning on the computer, replace all screws and ensure that no stray screws remain inside the computer. Failure to do so may
result in damage to the computer.
