Page 42
6.
Connect the left daughter board cable to the connector on the system board (see
Replacing the Left Daughter Board
).
7.
Connect the right daughter board cable to the connector on the system board (see
Replacing the Right Daughter Board
).
8.
Replace the Bluetooth™ card (see
Replacing the Bluetooth Card
).
9.
Replace the WLAN card (see
Replacing the WLAN Card
).
10.
Replace the solid state drive (see
Replacing the Solid State Drive
).
11.
Replace the memory module (see
Replacing the Memory Module
).
12.
Replace the thermal cooling assembly (see
Replacing the Thermal Cooling Assembly
).
13.
Replace the coin-cell battery (see
Replacing the Coin-Cell Battery
).
14.
Replace the keyboard (see
Replacing the Keyboard
).
15.
Replace the palm rest assembly (see
Replacing the Palm Rest Assembly
).
16.
Replace the computer battery (see
Replacing the Computer Battery
).
17.
Turn on the computer.
18.
Enter the service tag (see
Entering the Service Tag in the BIOS
Entering the Service Tag in the BIOS
1.
Ensure that the AC adapter is plugged in and that the main battery is installed properly.
2.
Turn on the computer.
3.
Press
4.
Navigate to the security tab and enter the service tag in the Set Service Tag field.
Back to Contents Page
CAUTION:
Before turning on the computer, replace all screws and ensure that no stray screws remain inside the computer. Failure to do so may
result in damage to the computer.
NOTE:
After you have replaced the system board, enter the computer Service Tag into the BIOS of the replacement system board.
