About Your System
63
5 module status indicator 6 power indicator
7 status/identification indicator
Table 1-16. Brocade M4424 SAN I/O Module Indicators
Indicator Type Pattern Description
Fibre Channel
port status
indicator Off No signal carrier
Amber on Signal present but not online
Green on Online, but no activity
Green blinking
slowly Online but segmented
Green blinking
quickly Internal loopback
Green flickering I/O activity on port
Amber blinking
slowly Port disabled
Amber blinking
rapidly Error or fault with port
Fibre Channel
port speed
indicator Off 1 Gb link established
Green on 2 Gb link established
Amber on 4 Gb link established
Module status
indicator Off Module is off or enclosure power is off.
Green on All ports are ready for use
Amber on Module is booting being reset, or ports are offline
Green/amber
blinking Diagnostic message in error log, or environmental
range exceeded
Module power
indicator Off Power to the module is off
Green Module has power.
Status/
identification
indicator Blue on Primary module in a stack, if applicable
Blue off Secondary module in a stack
Amber flashing Fault condition in module
