Dell Training Tool |
Latitude 13
Expand All
Collapse All
Introduction
Product Overview
Chassis
Field Service Information
Appendixes
Hard Drive Cable Kit
CAUTION:
before removing any part from the system.
Installing The Hard Drive Cable Kit
1. Pre-Removal Instructions
Technicians need to remove the following components prior proceeding to installing the hard drive cable kit:
1.
Remove the
2.
Remove the
3.
Remove the
4.
Remove the
2. Establishing image.
3. Disconnect both end of the existing hard drive flex cable from the system board and hard drive connectors.
4. The hard drive flex cable is attached with a double sided tape. Peel off the cable from the system.
5. Remove the cloth tape from the card reader board edge.
NOTE:
Skip this step if the cloth tape is not there.
