Dell Latitude 13 (Mid 2010) - Manual (Page 15)

NOTE: The ExpressCard slot does not support PC Cards.
ExpressCard connector ExpressCard slot
Cards supported 34-mm ExpressCards
Ports and Connectors
Audio microphone connector
stereo headphone/ speakers connector
Video 15-pin VGA connector
Network adapter RJ-45 connector
USB one 4-pin USB 2.0-compliant connector
one eSATA/USB 2.0-compliant connector
Memory-card slot 5-in-1 memory-card slot supporting MS, MS Pro, SD,
SDHC, and MMC cards
Mini Card PCI-E Half-Mini Card support for WLAN
PCI-E Mini Card support for WWAN
Display
Type white light emitting diode (WLED) anti-glare LCD
Size 13.3-inch high definition (HD)
Active area (X/Y) 293.40 mm x 165.00 mm
Dimensions:
Height 188.80 mm (7.43 inches)
Width 314.10 mm (12.37 inches)
Diagonal 337.80 mm (13.30 inches)
Maximum resolution 1366 x 768 pixels at 262 K colors
Typical brightness 200 nits
Operating angle 0 degree (closed) to 135 degrees
Refresh rate 40 Hz and 60 Hz
Viewing angles:
Horizontal 40/40 degrees
Vertical 15/30 degrees
Pixel pitch 0.2148 mm
Keyboard
Number of keys United States and Canada: 83 keys
International: 87 keys
Japan: 90 keys
Layout QWERTY/AZERTY/Kanji
Touchpad
Active area:
X-axis 81.00 mm (3.19 inches)
Y-axis 42.00 mm (1.65 inches)
Battery
Type 6-cell "smart" lithium-ion (30 WHr)
Charge time with computer off approximately 4 hours (on a fully discharged battery)
Operating time battery operating time varies depending on operating
conditions and can significantly reduce under certain
power-intensive conditions
Life span approximately 300 charge/discharge cycles
Dimensions:
Depth 155.20 mm (6.11 inches)
Height 5.35 mm (0.21 inches)
Width 177.60 mm (6.99 inches)
Voltage 11.10 VDC
Temperature range:
Operating 0 °C to 35 °C (32 °F to 95 °F)
Storage –40 °C to 60 °C (–40 °F to 140 °F)
Coin-cell battery 3 V CR2025 lithium
AC Adapter
