Camera
Dell™ Latitude™ 13 Service Manual
Removing the Camera
1. Follow the procedures in Before Working Inside Your Computer .
2. Remove the ExpressCard , if applicable.
3. Remove the SD card , if applicable.
4. Remove the base cover .
5. Remove the battery .
6. Remove the display bezel .
7. Remove the display panel .
8. Using a plastic scribe, gently pry the camera to release it from the display cover.
9. Disconnect the camera cable from the camera, and remove the camera from the computer.
Replacing the Camera
To replace the camera, perform the above steps in reverse order.
Back to Contents Page
WARNING: Before working inside your computer, read the safety information that shipped with your computer. For additional safety best
practices information, see the Regulatory Compliance Homepage at www.dell.com/regulatory_compliance.
NOTE: You may need to install Adobe® Flash® Player from Adobe.com in order to view the illustrations below.
