Type
Input voltage 100–240 VAC
Input current (maximum) 1.5 A
Input frequency 50 Hz–60 Hz
Output current 4.34 A (maximum at 4-second pulse)
3.34 A (continuous)
Output voltage 19.5 +/– 1.0 VDC
Dimensions:
Height 16 mm (0.63 inches)
Width 66 mm (2.60 inches)
Depth 127 mm (5.00 inches)
Weight (approximate) 0.29 kg (0.64 lb)
Temperature range:
Operating 0° C to 40° C (32° F to 104° F)
Storage –40° C to 70° C (–40° F to 158° F)
Physical
Height (front to back) 16.50 mm – 19.70 mm (0.65 inch – 0.78 inch)
Width 330 mm (12.99 inches)
Depth 230 mm (9.05 inches)
Weight (approximate) 1.60 kg (3.53 lb)
Environmental
Temperature range:
Operating 0° C to 35° C (32° F to 95° F)
Storage –40° C to 65° C (–40° F to 149° F)
Relative humidity (maximum):
Operating 10% – 90% (noncondensing)
Storage 5% – 95% (noncondensing)
Maximum vibration:
Operating 0.66 Grms (2 Hz–600 Hz)
Non-operating 1.30 Grms (2 Hz–600 Hz)
NOTE: Vibration is measured using a random-vibration spectrum that simulates user environment.
Maximum shock:
Operating 142 G (2 ms)
Non-operating 162 G (2 ms)
NOTE: Shock is measured with hard drive in head-parked position and a 2-ms half-sine pulse.
