Specifications
Dell™ Latitude™ 13 Service Manual
System Information
Memory
Audio
ExpressCard
Display
Touchpad
AC Adapter
Environmental
Processor
Video
Communications
Ports and Connectors
Keyboard
Battery
Physical
NOTE: Offerings may vary by region. For more information regarding the configuration of your computer, click Start® Help and Support and select the
option to view information about your computer.
System Information
Chipset Mobile Intel® GS45 Express Chipset
DRAM bus width 64-bit buses
Processor address bus width 36 bits
Flash EPROM SPI 16 Mbits
Processor
Types Intel Celeron® Ultra Low Voltage (ULV)
Intel Core™2 Solo ULV
Intel Core2 Duo ULV
L2 cache Intel Celeron ULV – 1MB
Intel Core2 Solo ULV – 3 MB
Intel Core2 Duo ULV – 3 MB
External bus frequency 800 MHz
Memory
Type DDR3
Speed supported: 1067 MHz
functional: 800 MHz due to limitations of the front
side bus (FSB)
Connector one SODIMM socket
Module capacities 1 GB, 2 GB, or 4 GB
Minimum memory 1 GB
Maximum memory 4 GB
Video
Type integrated on system board
Controller Intel GMA 4500MHD
Output 15-pin VGA connector
Audio
Type two-channel high definition audio
Controller Realtek ALC269
Stereo conversion 24-bit (analog-to-digital and digital-to-analog)
Interface:
Internal high definition audio
External microphone connector
stereo headphones/external speakers connector
Speakers one 1.5 W
Internal speaker amplifier 1.5 W
Volume controls keyboard function keys (Fn+F3/F4/F5) and program
menus
Communications
Network adapter 10/100/1000 Mbps Broadcom NetXtreme Ethernet
LAN
Wireless dedicated WLAN, WWAN, and Bluetooth® wireless
support if optional cards are purchased
ExpressCard
