Installing Enclosure Components
57
Removing Physical Disks from the Enclosure
NOTICE:
To avoid damage, never leave a physical disk carrier partially removed
from the enclosure. Rotating a carrier handle next to an unseated disk carrier will
result in serious damage to the unseated disk carrier.
NOTICE:
To avoid data loss when removing a physical disk, Dell recommends that
you verify with MD Storage Manager that the appropriate disk is being removed.
Removing an Assigned physical disk could result in data loss.
CAUTION:
Always wear a wrist grounding strap when handling equipment with
static-sensitive components.
1 Wait until the LED indicators on the physical disk carrier stop flashing.
2 Squeeze the release mechanism on the front of the physical disk carrier
(see Figure 3-2).
Figure 3-2. Installing and Removing Physical Disks
1 carrier release mechanism 2 disk carrier handle
1
2
