14
About Your System
Front-Panel Indicators and Features
Figure 1-2 shows the LED indicators and components on the enclosure’s
front panel (optional locking bezel not shown). Table 1-2 lists the conditions
and functions indicated by each.
Table 1-1. Front-Bezel Indicators
Item LED Indicator LED Icon Condition
1 Split mode (green) Because this mode is unused in the system,
this LED should always be unlit.
NOTE:
This LED comes on if the enclosure
mode switch on the enclosure’s front panel is
in the split mode position before the
enclosure is turned on.
2 Power (green) When lit, at least one power supply is
supplying power to the enclosure.
3 Enclosure status
(blue/amber) Steady amber: Power is on and enclosure is
in reset state.
Steady blue: Power is on and enclosure
status is OK.
Flashing blue: Enclosure LED is being
blinked by MD Storage Manager.
Flashing amber: Enclosure is in fault state.
