About Your System

21

4

iSCSI In Port 1 Link
Speed/Activity
Status LED

Green: Link is operating at 1000 Mbps.

Amber: Link is operating at 100 Mbps.

Off: iSCSI connection is not active.

5

Battery Fault LED
(amber)

Amber: Battery backup unit or battery has
failed or is missing.

Off: Battery backup unit and battery is
operating normally.

6

Cache Active LED
(green)

Green: On-board controller memory
contains data.

Off: On-board controller memory is empty.

7

iSCSI In Port 1

In-1

Provide host-to-controller iSCSI
connection. If LED is solid, there is no
activity on the link. If the LED is blinking,
there is activity on the link.

8

iSCSI In Port 1 Link
Duplex Mode

Green: Full-duplex mode.

Off: Half-duplex mode.

NOTE:

Half-duplex mode is supported only if

the link speed is 100Mbps.

9

Controller Fault
LED (amber)

Amber: Controller fault detected.

Off: Controller is operating normally.

10

Controller Power
LED (green)

Green: Controller power is on.

Off: Controller is not powered.

11

Ethernet Link LED
(green)

Green: Ethernet connection is active.

Off: Ethernet connection is not active.

12

Management Port
Ethernet Connector

Provide a 10/100 Mbps Ethernet
connection for out-of-band management of
the enclosure.

Table 1-4.

RAID Controller Module Component Functions (continued)

Item Component

Icon

Function
