Dell Latitude 120L - Manual (Page 80)

Type v.92 56K MDC
Controller Conexant CX11254/CX20493
Interface internal HDA bus
Network adapter 10/100 Ethernet LAN on system board
Wireless internal Mini PCI Wi-Fi wireless technology support
Video
Video type: integrated on system board
Video controller Intel Integrated Graphics Media Accelerator 900
Video memory Up to 64 MB of shared memory (when less than 512
MB system memory is installed.)
Up to 128 MB of shared memory (when more than
512 MB system memory is installed)
LCD interface LVDS
Audio
Audio type HDA bus
Audio controller STAC9200
Stereo conversion 18- or 24-bit (analog-to-digital and digital-to-analog)
Interfaces:
Internal HDA bus
External microphone-in connector, stereo
headphones/speakers connector
Speaker two 4-ohm speakers
Internal speaker amplifier 1-W channel into 4 ohms
Volume controls keyboard shortcuts, program menus
Display
Type (active-matrix TFT) 14.1-inch or 15.4-inch WXGA
Dimensions:
15.4-inch
Height 207 mm (8.2 inches)
Width 331.2 mm (13.1 inches)
Diagonal 391.2 mm (15.4 inches)
14.1-inch
Height 189.8 mm (7.5 inches)
Width 303.7 mm (11.9 inches)
Diagonal 358.1 mm (14.1 inches)
Maximum resolutions:
WXGA 1280 x 800 at 262,144 colors
Refresh rate 60 Hz
Operating angle 0° (closed) to 180°
Viewing angles:
Horizontal ±40° typical
Vertical +10°/–30°
Pixel pitch:
15.4-inch 0.2588 mm
14.1-inch 0.237 mm
Controls brightness can be controlled through keyboard
shortcuts
Keyboard
Number of keys 87 (U.S. and Canada); 88 (Europe);
91 (Japan)
Layout QWERTY/AZERTY/Kanji
Touch Pad
X/Y position resolution (graphics table mode)
240 cpi
