Dell Latitude 120L - Manual (Page 61)

5. Ease the hinge cover up, moving from right to left, and remove it.
6. To replace the hinge cover, insert the left edge of the cover into place.
7. Press from left to right until the cover snaps into place.
8. Close the display and turn the computer upside down.
9. Replace the battery. See Replacing the Battery .
Keyboard
1. Follow the procedures in Before You Begin .
2. Remove the hinge cover. See Hinge Cover .
3. Remove the two screws at the top of the keyboard.
4. Lift up the keyboard, and hold it up and slightly forward to allow access to the keyboard connector on the system board.
5. Lift the keyboard connector and slide out the keyboard cable.
6. To replace the keyboard, connect the keyboard connector to the system board.
7. Place the tabs along the front edge of the keyboard into the palm rest and lay the keyboard down on the palmrest.
8. Replace the two screws at the top of the keyboard.
9. Replace the hinge cover. See Hinge Cover .
1 hinge cover 2 indent
CAUTION: Before you begin any of the procedures in this section, follow the safety instructions in the Product Information Guide.
NOTICE: To avoid electrostatic discharge, ground yourself by using a wrist grounding strap or by periodically touching an unpainted metal surface (such
as a connector on the back of the computer).
NOTICE: The keycaps on the keyboard are fragile, easily dislodged, and time-consuming to replace. Be careful when removing and handling the
keyboard.
NOTICE: To avoid scratching the palm rest when replacing the keyboard, hook the tabs along the front edge of the keyboard into the palm rest, and
then secure the keyboard in place.
