Back view, Bottom view – Dell Latitude 120L User Manual
Page 5
Back View
AC adapter connector —
Attaches an AC adapter to the computer.
The AC adapter converts AC power to the DC power required by the computer. You can connect the AC adapter with your computer turned either on or off.
air vent —
The computer uses fans to create airflow through the vents, which prevents the computer from overheating.
Bottom View
1
2
CAUTION:
The AC adapter works with electrical outlets worldwide. However, power connectors and power strips vary among countries. Using an
incompatible cable or improperly connecting the cable to the power strip or electrical outlet may cause fire or equipment damage.
NOTICE:
When you disconnect the AC adapter cable from the computer, grasp the connector, not the cable itself, and pull firmly but gently to avoid
damaging the cable.
CAUTION:
Do not block or push objects into the air vents. Do not store your computer in a low-airflow environment, such as a closed briefcase,
while it is running. Restricting the airflow can damage the computer or cause a fire.
