Dell PowerVault DL2100 - Manual (Page 80)

80
Installing System Components
Figure 3-4. Removing the Information Tag
Installing the Information Tag
1 Align the information tag with the slot on the chassis.
2 Slide the information tag into the chassis, until it locks into place
Hard Drives
Your system supports up to six 3.5-inch hot-swappable SAS and SATA hard
drives.
The hard drives are installed at the front of the system and connect to the
system board through the SAS backplane. Hard drives are supplied in special
hot-swappable hard-drive carriers that fit in the hard-drive bays.
CAUTION:
Before attempting to remove or install a drive while the system is
running, see the documentation for the storage controller card to ensure that the
host adapter is configured correctly to support hot-swap drive removal and
insertion.
1 information tag
1
