Hard-Drive Indicator Patterns for RAID
Figure 1-3.
Hard-Drive Indicators
Power
Displays the power output of the system in BTU/hr or
Watts. The display format can be configured in the "Set
home" submenu of the Setup menu (see "Setup
Menu").
Temperature
Displays the temperature of the system in Celsius or
Fahrenheit. The display format can be configured in the
"Set home" submenu of the Setup menu (see "Setup
Menu").
1
drive-activity indicator (green)
2
drive-status indicator
Option
Description
1
2
