Dell Inspiron XPS - Manual (Page 146)

146
Appendix
www
.dell.com | support.dell.com
Display
Type (active-matrix TFT) WUXGA; WSXGA+; WXGA
Dimensions:
Height 222.5 mm (8.8 inches)
Width 344.5 mm (13.6 inches)
Diagonal 391.2 mm (15.4 inches)
Maximum resolutions 1920 x 1200 (WUXGA);
1680 x 1050 (WSXGA+);
1280 x 800 (WXGA)
Response time (typical) 20-ms rise (maximum),
35-ms fall (maximum)
Refresh rate 60 Hz
Operating angle 0 ° (closed) to 180°
Viewing angles:
Horizontal ±55°
Vertical ±48°
Pixel pitch 0.1725 mm (WUXGA)
0.1971 mm (WSXGA+)
0.2588 mm (WXGA)
Power Consumption:
Panel with backlight (typical) 7.0 W (WUXGA)
6.0 W (WSXGA+)
5.5 W (WXGA)
Controls brightness can be controlled through key
combinations
Keyboard
Number of keys 87 (U.S. and Canada); 88 (Europe); 91
(Japan)
Layout QWERTY/AZERTY/Kanji
