Adding and Replacing Parts
139
Display Latch Release
CAUTION:
Before you begin this procedure, read the safety instructions at the front of this document
(see page 11).
NOTICE:
To avoid electrostatic discharge, ground yourself by using a wrist grounding strap or by
periodically touching a connector on the back panel of the computer.
1 Remove the hard drive (see page 105).
2 Remove the keyboard (see page 114).
3 Remove the display (see page 124).
4 Remove the palm rest (see page 130).
5 Remove the system board (see page 135).
6 Remove the speakers (see page 138).
7 Remove the two M2.5x 6-mm screws on each side of the latch.
8 Pull the latch straight up and away from the computer base.
M2.5 x 6-mm screws (2) computer base
display latch release
