Four-Post Rack Installation
21
5 Locate the releasable tie wrap attachment points located on the two back mounting-bracket flanges
(see Figure 1-11).
These tie wraps are used to secure the system’s cables to the mounting rails.
Figure 1-11. Installing the Releasable Tie Wraps
6 Push the tie wrap’s fastener through the attachment point.
7 Push the tie wrap’s plunger until it snaps to secure the tie wrap to the mounting rail.
8 Using the releasable tie wrap, secure your system’s cables to the mounting rail.
1 mounting rails (2) 2 releasable tie wraps (2)
1
2
