Kyle Form 5, Form 5 UDP, Form 5 DC NOVA Recloser Control Installation and Operation Instructions
30
Standard and UDP Control DIF Module 2
Outputs
The 12 outputs of the DIF Module are Form C relay contacts. Six of the outputs are latching and six are non-latching.
Note:
Contacts shown in inactive mode.
Output Connector
Function
Type
Description
1
P3-1 (NC)
Control Lockout
Non-Latched
P3-2 (NO)
2
P3-3 (NC)
Check Battery
Non-Latched
P3-4 (NO)
3
P3-5 (NC)
Reverse Power Flow
Non-Latched
P3-6 (NO)
4
P3-7 (NC)
Fast Trips Disabled
Non-Latched
P3-8 (NO)
5
P3-9 (NC)
Operation Counter
Non-Latched
P3-10 (NO)
6
P3-11 (NC)
Recloser Malfunction
Non-Latched
P3-12 (NO)
7
P2-1 (NO)
Bushings 1-2 Fault Target
Latched
P2-2 (NC)
8
P2-3 (NO)
Bushings 3-4 Fault Target
Latched
P2-4 (NC)
9
P2-5 (NO)
Bushings 5-6 Fault Target
Latched
P2-6 (NC)
10
P2-7 (NO)
Ground Fault Target
Latched
P2-8 (NC)
11
P2-9 (NO)
Sensitive Ground Fault Target
Latched
P2-10 (NC)
12
P2-11 (NO)
Sensitive Ground Fault Blocked
Latched
P2-12 (NC)
This output is active when the CONTROL LOCKOUT
indicator is illuminated.
This output is active when the CHECK BATTERY indi-
cator is illuminated.
This output is active when the REVERSE POWER
FLOW indicator is illuminated.
This output is active when the FAST TRIPS DIS-
ABLED indicator is illuminated.
If the Supervisory function is enabled, this output is
active when the OPERATION COUNTER OFF inputs
from Comm Port 1-DIF2, Comm Port 2 and Comm Port
3 are not active.
This output is active when the RECLOSER MAL-
FUNCTION indicator is illuminated.
This output is active when the BUSHINGS 1-2 FAULT
TARGET indicator is illuminated.
This output is active when the BUSHINGS 3-4 FAULT
TARGET indicator is illuminated.
This output is active when the BUSHINGS 5-6 FAULT
TARGET indicator is illuminated.
Output is active when the GROUND FAULT TARGET
indicator is illuminated.
Output is active when the SENSITIVE GROUND
FAULT TARGET indicator is illuminated.
Output is active when Sensitive Ground Fault is
blocked.
