PowerStorm 300 AGP Graphics Controller Overview
PowerStorm 300 AGP and 300/350 PCI Graphics Controllers 1–5
1.4 Specifications
Table 1-3 lists the specifications for the PowerStorm 300 AGP graphics controller.
Table 1-3 PowerStorm 300 AGP Graphics Controller Specifications
Resolution 1280 x 1024 (maximum) @ 85 Hz
Color planes 24-bit, double buffered
Overlay planes 8-bit, shared with alpha planes
4-bit, shared with stencil planes
Stencil planes 4-bit, shared with overlay planes
Alpha planes 8-bit, shared with 8 bit overlay planes
Window ID 4-bit
Z-buffer 24-bit
Total bits/pixel 96
Frame buffer 15 MB
Texture memory 16 MB
Form factor Single full-length AGP card in ATX or NLX
form
AGP AGP 1X, 32-bit, 66 MHz, 5V signaling
Input voltage 3.3 Vdc, 5 Vdc, +12 Vdc
Power 25 W maximum
Operating temperature 10°C to 35°C (50°F to 104°F)
Relative humidity 10% to 90% noncondensing
