PowerStorm 300 AGP Graphics Controller Overview
PowerStorm 300 AGP and 300/350 PCI Graphics Controllers 1–3
Figure 1-2 PowerStorm 300 AGP Graphics Controller (NLX)
ML014616
1
3
4
2
➊
Standard 15-pin VGA connector
③
Shows the jumper set for VGA enabled
(default)
➋
VGA enable/disable jumper
④
Shows the jumper set for VGA
disabled
