This command is not available on the DFI 1550.
FB
Clear Peak and Valley Data
Purpose
To reset the channel's peak and valley data values to the track value.
Usage
"#aaccFB
↵"
# is the 'pound' or 'hash' character (ASCII decimal 35).
aa is the two-character instrument address.
cc is the two-character channel number
↵ is the 'carriage return' character (ASCII decimal 13).
Example
"#0001FB
↵"
Reply
"OK" or "N/A"
Remarks
This command is not available on the DFI 1550.
FF
Transmit Analog-to-Digital Converter Reading
Purpose
To transmit the Analog-to-Digital converter reading as a percentage from -100% to
+100% of the A/D converter’s full scale.
Usage
“#aaccFF
↵"
# is the 'pound' or 'hash' character (ASCII decimal 35).
aa is the two-character instrument address.
cc is the two-character channel number
↵ is the 'carriage return' character (ASCII decimal 13 ).
Example
“#0001FF
↵”
Reply
" 872945" (typical)
Remarks None
FH
Write DAC Control Value
Purpose
To control the channel's Digital-to-Analog Converter (DAC) manually or automatically
Usage
“#aaccFHn
↵"
# is the 'pound' or 'hash' character (ASCII decimal 35).
aa is the two-character instrument address.
cc is the two-character channel number.
n is the argument defined below.
↵ is the 'carriage return' character (ASCII decimal 13).
Argument
"AUTO" returns the DAC to its normal automatic operation (power-on default). That is, it
is controlled by the "DAC. CHANNEL", "DAC. SOURCE", "DAC. ZERO-SCALE" and
"DAC. FULL-SCALE" menu items.
If the argument is a numeric value between -1 and +1, the DAC is forced to manual
control and the value is used to drive the DAC from -100% to + 100% of its output.
Example
"#0001FH. 5
↵" will force channel 01 's DAC to +50% of full-scale.
Reply
OK" or "ERROR
Remarks
You might wish to force a channel's DAC to a certain output to help calibrate the attached
data acquisition system or other device.
R5/W5
Read/write Full-Scale Value
Purpose
Reads or writes the channel's "FULL SCALE VALUE" menu item
Usage
"#aaccR5
↵" to read, "#aaccW5n↵" to write.
# is the 'pound' or 'hash' character (ASCII decimal 35).
aa is the two-character instrument address.
cc is the two-character channel number
n is the full-scale value in engineering units.
↵ is the 'carriage return' character (ASCII decimal 13).
Example
"#0001W520000
↵”
Reply
When writing: "OK" or "ERROR".
When reading: an ASCll-floating-point value.
Changing this value has no effect until the channel is re-calibrated to the transducer.
