CF 126

37

Nov 2001

Example

“#0001F0

↵"

Reply

“5670.5" (typical)

Remarks

The input channel continuously reads the transducer. This function transmits the most
recent reading.


F1

Activate Tare

Purpose

To reset the channel's data values to zero

Usage

“#aaccF1

↵"

# is the 'pound' or 'hash' character (ASCII decimal 35).
aa is the two-character instrument address.
cc is the two-character channel number
↵ is the 'carriage return' character (ASCII decimal 13).

Example

“#0001F1

↵"

Reply

"OK"


F2

Deactivate Tare

Purpose

To remove the offset from the channel's data values which was applied when tare was
activated.

Usage

"#aaccF2

↵"

# is the 'pound' or 'hash' character (ASCII decimal 35).
aa is the two-character instrument address.
cc is the two-character channel number
↵ is the 'carriage return' character (ASCII decimal 13).

Example

"#0001F2

↵"

Reply "OK"


F5

Apply Shunt Resistor and Transmit Reading

Purpose

To apply the channel's internal shunt resistor to the transducer and transmit a reading.

Usage

"#aaccF5

↵"

# is the 'pound' or 'hash' character (ASCII decimal 35).
aa is the two-character instrument address.
cc is the two-character channel number
↵ is the 'carriage return' character (ASCII decimal 13).

Example

"#0001F5

↵”

Reply

A numeric data reading or "N/A"

Remarks

This can be used as a quick check to verify that the transducer is operating properly.


F9

Transmit Peak Data

Purpose

To transmit the channel's peak data value

Usage

"#aaccF9

↵"

# is the 'pound' or 'hash' character (ASCII decimal 35).
aa is the two-character instrument address.
cc is the two-character channel number
↵ is the 'carriage return' character (ASCII decimal 13).

Example

"#0001F9

↵ "

Reply

" 12620.5" (typical) or "N/A"

Remarks

This command is not available on the DFI 1550.


FA

Transmit Valley Data

Purpose

To transmit the channel's valley data value

Usage

"#aaccFA

↵"

# is the 'pound' or 'hash' character (ASCII decimal 35).
aa is the two-character instrument address.
cc is the two-character channel number
↵ is the 'carriage return' character (ASCII decimal 13).

Example

"#0001FA

↵"

Reply

"-0012.5" (typical) or "N/A"
