CF 126 17 Nov 2001
aa is the two-character instrument address.
n is the argument defined below.
↵ is the 'carriage return' character (ASCII decimal 13).
Argument “0” disables the auto line-feed function. Each reply ends only with a carriage return.
“1” enables the auto line-feed function (default). Each reply ends with a line-feed/carriage-
return combination.
Example “#00W20 ↵”
Reply “OK” or “ERROR”
W4 Write Address
Purpose Writes a new baud rate for serial communications
Usage "#aa W4 nn. ↵"
# is the 'pound' or 'hash' character (ASCII decimal 35).
aa is the old two-character instrument address.
nn is the new two-character instrument address.
↵ is the 'carriage return' character (ASCII decimal 13).
Example “#00W402 ↵”
Reply "OK" or "ERROR".
Remarks
Each character of the new address must be alphanumeric.
Lower-case characters are converted to upper case.
As shipped from the factory, DFI instruments are set to communicate at address 00.
To determine what address the instrument is using from the front panel:
1) Enter the setup menus by pressing [UP] and [DOWN] together. The display will read
"
SETUP " and then " CHANNEL 01 MENU " (which is the top-most item on the setup menus).
2) Press and release [DOWN] until the display reads " SERIAL COM. MENU ". Press
[ENTER] to enter the SERIAL COM. menu.
3) Press and release [DOWN] until the display reads "
ADDRESS ".
Press [ENTER] and the display will show the address. The address cannot be changed
from the front panel, only from the serial port.
4) Press [EXIT] to exit the menus and restart the instrument.
RA/WA Read/write Limit Set Point
Purpose Reads or writes the SET POINT of a limit.
Usage “aa RA pp ↵”to read, “aa WA appn ↵“ to write.
# is the 'pound' or 'hash' character (ASCII decimal 35).
aa is the two-character instrument address.
pp is the two-numeric-character limit number.
n is the limit SET POINT value.
↵ is the 'carriage return' character (ASCII decimal 13).
Example Sending “#00WA01325.2 ↵“ will change the SET POINT of Limit 1 to 325.2.
Reply When writing: "OK", "ERROR" or "N/A"
When reading: a floating-point value, or "N/A".
Remarks This command does not apply to instruments not equipped with limits, such as the DFI
1550.
RB/WB Read/write Limit Return Point
Purpose Reads or writes the RETURN POINT of a limit.
Usage “aa RB pp ↵” to read, “#aa WB ppn ↵” to write.
# is the 'pound' or 'hash' character (ASCII decimal 35).
aa is the two-character instrument address.
pp is the two-numeric-character limit number.
n is the limit RETURN POINT value.
↵ is the 'carriage return' character (ASCII decimal 13).
