S2: Displays M/^ representing Motion / Stable, respectively.
•
S3: Displays Z/^ representing center of Zero / Non-Zero, respectively.
•
S4: Displays - representing single range.
•
Printing
The instrument has a single fixed printing format that is as follows:
000048 06/05/2003 15:10
121.4 lb G
The first line contains a six digit sequential number that is automatically incremented with each printing, up to a
maximum of 999999. The first line also contains the current date and time, printed in the selected format. The
second line shows the displayed reading, units and G for Gross or N for Net.
If counting is active, the printout has a third line for the counting information (p for pieces) as follows:
164 p
Whenever a new sample is taken when counting, the instrument prints the sample as in the following format:
SAMPLE: 100 p = 50.0 lb
In addition to the printout, the instrument adds the weight and pieces printed to the internal weight and count totals.
A long press of the
Following is a sample of a total ticket:
000049 06/05/2003 15:20
90.6 lb G
000050 06/05/2003 15:21
154.9 lb G
000051 06/05/2003 15:21
50.4 lb G
000052 06/05/2003 15:21
71.0 lb G
000053 06/05/2003 15:21
13.3 lb G
ITEMS:
5
TOTAL:
380.2 lb
If counting is active each of the individual printouts would have a third line as discussed above and the
TOTAL would have an additional QTY line as follows:
000054 06/05/2003 15:22
13.3 lb G
27 p
000055 06/05/2003 15:23
79.3 lb G
159 p
000056 06/05/2003 15:23
117.0 lb G
234 p
ITEMS:
3
TOTAL:
209.6 lb
QTY:
420 p
9.2 Master Serial Output
In Master mode, the instrument sends out the entire contents of the LCD every 100msec. This is essentially the
same as AUTO output but the format of the output string is designed to allow a remote display to exactly copy the
contents of the LCD including all of the annunciators and user prompts, etc.
