Appendix B: System Specifications
Electrophoresis Station
Material
Casing
ABS, polycarbonate (gray)
Lid
Polycarbonate (translucent green)
Open latch
Polycarbonate (khaki)
Rubber feet
Thermoplastic rubber
Power button
ABS, polycarbonate (green)
Technical
Power supply
100–240 VAC, 50/60 Hz, 31 VA
Power indicator
LED
Electrode wires
90% Platinum, 10% iridium alloy, 0.5 mm diameter
Laser
Photo diode, 635 nm excitation
Laser
Safety Class 1 product (nonhazardous)
Detector
Photoemission, 685 nm emission
Voltage limit
2,200 V (when multiple channels are driven)
Operating conditions
15–40°C, 0–90% humidity
Safety conformances
U.S.
IEC 61010-1, EN 61010-1:2001, and UL 61010-1
Canada
CAN/CSA C22.2 No. 61010-1
EMC compliance
EN 61326: Class A
Computer connection USB2 cable
Weight
4.58 kg (10 lb 1 oz)
Dimensions
15 x 31 x 29 cm
Priming Station
Material
Base casing
Glass-filled polycarbonate (gray)
Lid
Polycarbonate (translucent green)
Open latch
Polycarbonate (khaki)
Rubber feet
Thermoplastic rubber
Priming seal
Silicone rubber
