Great Plains Mfg., Inc.
Installation Instructions 29
11/08/2006 148-771M
Open Center Down-Pressure Components
Ref. Part No. Part Description Comment
1 148-768S 5.625 CYL DEPTH CHNL ASSY
2 890-005C BUSHING CYL 1 1/4 X 1 X 1
3 148-771M MANUAL 04 HOSE SUPPORT UPDATE
4 248-506D OPNR DOWN PRESSURE VALVE MNT
5 248-507D CYLINDER PIN
6 248-508D TOP LINK CYL LUG
7 800-035C CABLE TIE .31X28 8DIA 120LB
8 800-245C SNAP RING EXT 1 5304
9 802-024C HHCS 3/8-16X3 GR5
10 802-082C HHCS 1/2-13X1 3/4 GR5
11 802-114C HHCS 3/8-16X2 1/2 GR5
12 802-551C HHCS 1/4-20X2 1/4 GR5
13 803-006C NUT HEX 1/4-20 PLT
14 803-014C NUT HEX 3/8-16 PLT
15 803-020C NUT HEX 1/2-13 PLT
16 803-078C NUT LOCK 3/8-16 NYLON INSERT
17 804-006C WASHER LOCK SPRING 1/4 PLT
18 804-013C WASHER LOCK SPRING 3/8 PLT
19 804-015C WASHER LOCK SPRING 1/2 PLT
20 804-075C WASHER FLAT 1/4 USS PLT
21 804-087C WASHER FLAT 3/8 HARD ASTMF436
22 804-113C WASHER FLAT 1/2 USS HARD PLT
23 810-162C CYL 3.5X8X1.25 ROD (TIE ROD)
24 810-300C PRESSURE GAUGE 3000 PSI
25 810-301C VALVE PRESS REDUCING W/CHECK
26 810-343C VALVE PO CHECK 2:1 W/9/16FORB
27 810-344C VALVE SHUTTLE 9/16FORB PORTS
28 810-428C VALVE PO CHECK 4:1 W/9/16FORB
29 810-432C HYDRAULIC BYPASS VALVE
30 810-554C FILTER INLINE 3/4FORB 3/4MJIC
31 811-061C TE 9/16MJIC 9/16MJIC 9/16FJIC
32 811-063C EL 3/4MJIC 3/4MORB
33 811-064C TE 9/16MJIC 9/16MJIC 9/16MORB
34 811-065C EL 9/16MJIC 9/16MORB
35 811-169C EL 9/16MJIC 9/16FJIC
36 811-170C AD 9/16MORB 9/16MJIC
37 811-171C EL 3/4MORB 9/16MJIC
38 811-216C EL 3/4MJIC 9/16MORB
39 811-249C TE 9/16MJIC 3/4MORB 9/16MJIC
40 811-439C TE 9/16MORB 9/16MJIC 9/16MJIC
41 811-582C AD 9/16MORB 1/4FNPT
42 811-627C AD 9/16MORB 9/16FJIC
43 811-636C AD 9/16MORB STRAIGHT UNION
44 811-675C PL 9/16MORB HEX HEAD
45 841-077C EL 3/4FJIC 3/4MORB
46 811-699C HH3/8R2 106 9/16FJIC
47 811-702C HH3/8R2 017 9/16FJIC
48 811-705C HH3/8R2 050 9/16FJIC
49 811-922C HH3/8R2 045 9/16FJIC
50 811-926C HH3/8R2 022 9/16FJIC
51 841-136C HH3/8R2 015 9/16FJIC 3/4FJIC
