Great Plains P17921E Operator Manual - Manual (Page 97)

97 UniPress
Operating Instructions
7. Parts and Assembly
AS4184 TINE FRAME ASSEMBLY LH - 5.5m
ITEM PART NO DESCRIPTION QTY COMMENTS
1 AS4175 PROACTIVE TINE ASSEMBLY - SPRING ONLY 9
2 AS4176 TINE ASSEMBLY - STRAIGHT TINE 9
3 P02009 NUT LOCK M20 8
4 P02603 WASHER FLAT M20 8
5 P02655 BOLT M20x240 GR. 8.8 8
6 P04053 CLAMP PLATE 2x122x22 2
7 P09432 RETAINING PLATE 120x120x4 1
8 P12118 TINE FRAME LH - 5.5 + 6.1m 1
