69 UniPress
Operating Instructions
7. Parts and Assembly
AS3707 REAR DRAWBAR ASSEMBLY
ITEM PART NO DESCRIPTION QTY COMMENTS
1 P00160 CYLINDER - Ø3¾"x9" - 45 1
2 P00200 BANJO BLOCK ½" BSP 2
3 P00201 BANJO BOLT ½" BSP 2
4 P00203 ADAPTOR MALE-MALE ½" BSP 5
5 P00206 ADAPTOR MALE-FEM ½" BSP 1
6 P00774 SHUT OFF TAP ½" BSP 5
7 P01274 PIN Ø25x115 2
8 P01645 BUSH SPRUNG - Ø32xØ26x30 2
9 P02007 NUT LOCK M12 2
10 P02011 NUT LOCK M30 2
11 P02263 DOWTY SEAL ½" BSP 18
12 P02484 LYNCH PIN CAT 2 2
13 P02486 R CLIP Ø7x170 2
14 P02601 WASHER FLAT M12 4
15 P02608 WASHER FLAT M30 2
16 P02730 QUICK RELEASE FEM. ½" BSP 4
17 P02735 BULKHEAD ½" BSP 4
18 P02793 BOLT M30x220 GR. 8.8 2
19 P03219 PIN Ø36x160 1
20 P04418 PIN Ø25x230 TYPE B 1
21 P08564 TRAILER SOCKET FEMALE 12N KIT 1
22 P10073 DRAWBAR CLEVIS 1
23 P10870 BOLT M12x30 GR. 8.8 2
24 P12425 SOCKET 12N - BOOT 1
25 P12426 SOCKET 12N - INSTALL KIT 1
26 P15835 BULK HEAD PLATE 1
27 P17135 REAR DRAWBAR 1
