143 UniPress
Operating Instructions
7. Parts and Assembly
AS2830 LEVELLING BOARD ASSEMBLY RH OUTER
UNIPRESS 8.2m
ITEM PART NO DESCRIPTION QTY COMMENTS
1 P00006 BOLT M12x80 GR. 8.8 1
2 P01281 BOLT M12x100 GR. 8.8 9
3 P01619 BOLT U M20 GR8.8 145x172 4
4 P02007 NUT LOCK M12 14
5 P02008 NUT LOCK M16 4
6 P02009 NUT LOCK M20 8
7 P02483 LYNCH PIN CAT 1 4
8 P02601 WASHER FLAT M12 19
9 P02602 WASHER FLAT M16 4
10 P02603 WASHER FLAT M20 8
11 P03088 BOLT M12x60 GR. 8.8 4
12 P04126 BUSH SPRUNG - Ø32xØ26x20 2
13 P06802 BOLT U M16 GR8.8 190x117 2
14 P07545 PLASTIC END CAP 60x60 1
15 P07724 PIN Ø25x100 2
16 P08013 CYLINDER - Ø63x130 - 32 1
17 P08802 SHIM KIT 7 PIECE 1
18 P09400 SHIM KIT PLATE Ø1¼" ROD 1
19 P12677 LEVELLING BOARD PILLAR 2
20 P13402 LEAF CLAMP 60x60 RHS 9
21 P13406 BOLT M10x35 DOME SQ. 18
22 P13407 NUT TOOTHED M10 18
23 P13416 SPRUNG LEAF 80x10 9
24 P13417 WEAR PLATE 80mm 9
25 P15230 PILLAR DISC - SQUARE 1
26 P15231 LOCKING COLLAR 2
27 P15232 CYLINDER PLATE SQUARE 2
28 P15233 RAM POINT - UPPER 1
29 P15235 LEVELLING BEAM 2000mm 1
30 P16348 LEVELLING BOARD TIE 1
