41 UniPress
Operating Instructions
7. Parts and Assembly
AS3732 GENERAL ASSEMBLY - 4.6m
ITEM PART NO DESCRIPTION QTY COMMENTS
1 AS3008 WING ASSEMBLY RH - 4.6m 1
2 AS3009 WING ASSEMBLY LH - 4.6m 1
3 AS3308 LEVELLING BOARD ASSEMBLY 4.6m LH 1
4 AS3309 LEVELLING BOARD ASSEMBLY 4.6m RH 1
5 AS3707 REAR DRAWBAR ASSEMBLY 1
6 AS3709 DRAWBAR ASSEMBLY - 4.6 - 6.6m 1
7 AS3711 LIGHT KIT FRONT 1 OPTION
8 AS3712 REAR LIGHT BRACKETS 1
9 AS3713 CHASSIS ASSEMBLY - 4.6m - 6.6m 1
10 AS3743 UNIPRESS STICKER LAYOUT 4.6M 1
11 AS4163 WING ASSEMBLY RH - 4.6m 1
12 AS4164 WING ASSEMBLY LH - 4.6m 1
13 AS4181 TINE FRAME ASSEMBLY RH - 4.6m 1
14 AS4182 TINE FRAME ASSEMBLY LH - 4.6m 1
15 P17921 MANUAL - UNIPRESS 2011 1
