107 UniPress
Operating Instructions
7. Parts and Assembly
AS4191 TINE FRAME ASSEMBLY RH - 8.2m
ITEM PART NO DESCRIPTION QTY COMMENTS
1 AS4175 PROACTIVE TINE ASSEMBLY - SPRING ONLY 13
2 AS4176 TINE ASSEMBLY - STRAIGHT TINE 13
3 P02009 NUT LOCK M20 12
4 P02603 WASHER FLAT M20 12
5 P02655 BOLT M20x240 GR. 8.8 12
6 P09432 RETAINING PLATE 120x120x4 3
7 P12125 TINE FRAME RH - 8.2m 1
