Great Plains P17921E Operator Manual - Manual (Page 127)

127 UniPress
Operating Instructions
7. Parts and Assembly
AS3303
ITEM PART NO DESCRIPTION QTY COMMENTS
1 P01224 BOLT M20x180 GR. 8.8 4
2 P01281 BOLT M12x100 GR. 8.8 13
3 P01619 BOLT U M20 GR8.8 145x172 4
4 P02007 NUT LOCK M12 19
5 P02009 NUT LOCK M20 12
6 P02483 LYNCH PIN CAT 1 4
7 P02601 WASHER FLAT M12 25
8 P02603 WASHER FLAT M20 16
9 P03088 BOLT M12x60 GR. 8.8 6
10 P04126 BUSH SPRUNG - Ø32xØ26x20 2
11 P07545 PLASTIC END CAP 60x60 2
12 P07724 PIN Ø25x100 2
13 P08013 CYLINDER - Ø63x130 - 32 1
14 P08802 SHIM KIT 7 PIECE 1
15 P09400 SHIM KIT PLATE Ø1¼" ROD 1
16 P12675 UPPER RAM POINT 1
17 P12677 LEVELLING BOARD PILLAR 3
18 P13402 LEAF CLAMP 60x60 RHS 13
19 P13406 BOLT M10x35 DOME SQ. 26
20 P13407 NUT TOOTHED M10 26
21 P13416 SPRUNG LEAF 80x10 13
22 P13417 WEAR PLATE 80mm 13
23 P15230 PILLAR DISC - SQUARE 2
24 P15231 LOCKING COLLAR 4
25 P15232 CYLINDER PLATE SQUARE 2
26 P16038 LEVELLING BEAM 2930mm 1
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
LEVELLING BOARD ASSEMBLY - 6.6m RH
