49 UniPress
Operating Instructions
7. Parts and Assembly
AS4156 GENERAL ASSEMBLY - UNIPRESS
8.2m
ITEM PART NO DESCRIPTION QTY COMMENTS
1 AS2829 LEVELLING BOARD ASSEMBLY RH INNER 1
2 AS2830 LEVELLING BOARD ASSEMBLY RH OUTER 1
3 AS2831 LEVELLING BOARD ASSEMBLY LH INNER 1
4 AS2832 LEVELLING BOARD ASSEMBLY LH OUTER 1
5 AS3018 WING ASSEMBLY RH - 8.2m 1
6 AS3019 WING ASSEMBLY LH - 8.2m 1
7 AS3707 REAR DRAWBAR ASSEMBLY 1
8 AS3711 LIGHT KIT FRONT 1 OPTION
9 AS3712 REAR LIGHT BRACKETS 1
10 AS4016 UNIPRESS STICKER LAYOUT 8.2m 1
11 AS4158 CHASSIS ASSEMBLY HD 1
12 AS4160 DRAWBAR ASSEMBLY HD 1
13 AS4173 DD700 ROLL ASSEMBLY RH - 8.2m 1
14 AS4174 DD700 ROLL ASSEMBLY LH - 8.2m 1
15 AS4191 TINE FRAME ASSEMBLY RH - 8.2m 1
16 AS4192 TINE FRAME ASSEMBLY LH - 8.2m 1
17 P17921 MANUAL - UNIPRESS 2011 1
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
