151 UniPress
Operating Instructions
AS4165 DD700 ROLL ASSEMBLY RH - 5.5m
ITEM PART NO DESCRIPTION QTY COMMENTS
1 AS0643 AXLE ASSEMBLY - DD700 7 RINGS 1
2 AS0775 AXLE ASSEMBLY - DD700 5 RINGS 1
3 P02008 NUT LOCK M16 'TYPE T' 14
4 P02037 WASHER SPRING M12 22
5 P02602 WASHER FLAT M16 14
6 P04179 WASHER FLAT M12 Ø38 22
7 P06802 BOLT U M16 GR8.8 190x117 7
8 P09558 SCRAPER PLATE 9
9 P09559 SCRAPER STEM RH 1
10 P09560 SCRAPER STEM LH 6
11 P10029 SCRAPER 1 1/2 2
12 P10870 BOLT M12x30 GR. 8.8 22
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
7. Parts and Assembly
