43 UniPress
Operating Instructions
7. Parts and Assembly
AS4152 GENERAL ASSEMBLY - UNIPRESS
5.5m
ITEM PART NO DESCRIPTION QTY COMMENTS
1 AS3010 WING ASSEMBLY RH - 5.5m 1
2 AS3011 WING ASSEMBLY LH - 5.5 1
3 AS3306 LEVELLING BOARD ASSEMBLY 5.5m LH 1
4 AS3307 LEVELLING BOARD ASSEMBLY - 5.5m RH 1
5 AS3707 REAR DRAWBAR ASSEMBLY 1
6 AS3709 DRAWBAR ASSEMBLY - 4.2-6.6 1
7 AS3711 LIGHT KIT FRONT 1 OPTION
8 AS3712 REAR LIGHT BRACKETS 1
9 AS3713 CHASSIS ASSEMBLY - 4.6m - 6.6m 1
10 AS4011 UNIPRESS STICKER LAYOUT 5.5m 1
11 AS4165 DD700 ROLL ASSEMBLY RH - 5.5m 1
12 AS4166 DD700 ROLL ASSEMBLY LH - 5.5 1
13 AS4183 TINE FRAME ASSEMBLY RH - 5.5m 1
14 AS4184 TINE FRAME ASSEMBLY LH - 5.5m 1
15 P17921 MANUAL - UNIPRESS 2011 1
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
