Great Plains P17921E Operator Manual - Manual (Page 165)

165 UniPress
Operating Instructions
AS4174 DD700 ROLL ASSEMBLY LH - 8.2m
ITEM PART NO DESCRIPTION QTY COMMENTS
1 AS1208 AXLE ASSEMBLY - DD700 9 RINGS 2
2 P02008 NUT LOCK M16 'TYPE T' 26
3 P02037 WASHER SPRING M12 34
4 P02602 WASHER FLAT M16 26
5 P04179 WASHER FLAT M12 Ø38 34
6 P06802 BOLT U M16 GR8.8 190x117 13
7 P09558 SCRAPER PLATE 15
8 P09559 SCRAPER STEM RH 11
9 P09560 SCRAPER STEM LH 2
10 P10029 SCRAPER 1 1/2 2
11 P10870 BOLT M12x30 GR. 8.8 34
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
7. Parts and Assembly
