149 UniPress
Operating Instructions
AS4164 DD700 ROLL ASSEMBLY LH - 4.6m
ITEM PART NO DESCRIPTION QTY COMMENTS
1 AS1217 AXLE ASSEMBLY - DD700 10 RINGS 1
2 P02008 NUT LOCK M16 'TYPE T' 14
3 P02037 WASHER SPRING M12 18
4 P02602 WASHER FLAT M16 14
5 P04179 WASHER FLAT M12 Ø38 18
6 P06802 BOLT U M16 GR8.8 190x117 7
7 P09558 SCRAPER PLATE 7
8 P09559 SCRAPER STEM RH 6
9 P09560 SCRAPER STEM LH 1
10 P10029 SCRAPER 1 1/2 2
11 P10870 BOLT M12x30 GR. 8.8 18
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
7. Parts and Assembly
