119 UniPress
Operating Instructions
7. Parts and Assembly
AS3309
ITEM PART NO DESCRIPTION QTY COMMENTS
1 P01224 BOLT M20x180 GR. 8.8 4
2 P01281 BOLT M12x100 GR. 8.8 9
3 P01619 BOLT U M20 GR8.8 145x172 2
4 P02007 NUT LOCK M12 13
5 P02009 NUT LOCK M20 8
6 P02483 LYNCH PIN CAT 1 4
7 P02601 WASHER FLAT M12 17
8 P02603 WASHER FLAT M20 12
9 P03088 BOLT M12x60 GR. 8.8 4
10 P04126 BUSH SPRUNG - Ø32xØ26x20 2
11 P07545 PLASTIC END CAP 60x60 2
12 P07724 PIN Ø25x100 2
13 P08013 CYLINDER - Ø63x130 - 32 1
14 P08802 SHIM KIT 7 PIECE 1
15 P09400 SHIM KIT PLATE Ø1¼" ROD 1
16 P12675 UPPER RAM POINT 1
17 P12677 LEVELLING BOARD PILLAR 2
18 P13402 LEAF CLAMP 60x60 RHS 9
19 P13406 BOLT M10x35 DOME SQ. 18
20 P13407 NUT TOOTHED M10 18
21 P13416 SPRUNG LEAF 80x10 9
22 P13417 WEAR PLATE 80mm 9
23 P15230 PILLAR DISC - SQUARE 1
24 P15231 LOCKING COLLAR 2
25 P15232 CYLINDER PLATE SQUARE 2
26 P16050 LEVELLING BEAM 2010mm 1
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
LEVELLING BOARD ASSEMBLY - 4.6m RH
