Appendix 35
02/24/2010 175-253M
New Parts: Fertilizer Rate Adjuster Rod Assembly
New Parts: Accessory Drive
Subassembly: 150-044S FERTILIZER ADJUSTMENT ROD ASSY
Used in: 175-248A, 175-249A,
175-250A, 175-251A
Callout
Quantity
in Kit
Part
Number Description Remarks
1 150-049D HEX COUPLER ADJUSTMENT HANDLE pre-installed
1 150-050D FERTILIZER ADJUSTMENT ROD pre-installed
1 805-073C PIN ROLL 5/32 X 1 pre-installed
143
144
212
Subassembly: 175-266K 8FT EW AUX JACKSHAFT ASY Used in: 175-249A, 175-251A
Callout
Quantity
in Kit
Part
Number Description Remarks
3 120-305D TUBE RND 1 OD X 7/32W X 1.56
1 136-036D CHAIN RL #40 70 PITCHES
1 175-414D 8FT EW AUX JACK SHAFT MNT
1 175-415D 8FT EW AUX JACK SHAFT
1 402-058D COLLAR LOCK 7/8 HEX
1 800-141C SNAP RING EXT F/PEERLESS G.B.
2 801-035C SCREW SET 5/16-18 SKT KP X 3/8
3 802-226C HHCS 1/2-13X2 3/4 GR5
4 802-282C RHSNB 5/16-18X1 GR5
4 803-008C NUT HEX 5/16-18 PLT
4 803-014C NUT HEX 3/8-16 PLT
3 803-169C NUT HEX FLG. LOCK 1/2-13 PLT.
4 804-009C WASHER LOCK SPRING 5/16 PLT
4 804-013C WASHER LOCK SPRING 3/8 PLT
9 804-017C WASHER FLAT 1/2 USS PLT
2 805-180C PIN ROLL 1/4 X 1 1/2 LG PLT
2 806-004C U-BOLT 3/8-16 X 2 X 2 3/4
1 808-157C SPKT 40B19 X 36T SPLINE BORE
1 808-219C SPKT 40C12 X 7/8 HEX BORE
1 808-250C SPKT 40C22 X 7/8 HEX BORE
3 817-406C IDLER 1 PC 2.38X1.01X1.062
4 822-032C FLANGETTE 52 MST
2 822-195C BRG INS 7/8HEXX2.04OD SPH
103
111
149
150
159
165
170
179
181
188
190
195
201
203
206
213
214
219
221
222
229
232
235
