Great Plains 800EW Operator Manual - Manual (Page 36)

34 175-248A, -249A, -250A, -251A
175-253M 02/24/2010
New Parts: Fertilizer Box and Lid
Subassembly: 142-266L FERT. BOX & LID ASY
Used in: 175-248A, 175-249A,
175-250A, 175-251A
Callout
Quantity
in Kit
Part
Number Description Remarks
1 120-234D RND SHAFT 3/4 X 13 3/8 W/KW pre-installed
1 120-293D TUBE RND DOM. 1 OD X 7/32WX3.0 pre-installed
2 123-580D BRG PLATE - ASSEMBLY pre-installed
1 142-141D LID HANDLE pre-installed
1 142-236D FERT BOX PARTITION pre-installed
1 142-256D FERT BOX MOUNT BRACKET pre-installed
1 142-258H 8’ FERT BOX WELDMENT pre-installed
1 142-259H 8’ FERT/NG BOX LID WELDMENT pre-installed
1 142-589S 3PT FERT BOX LID HINGE ASSY LH pre-installed. see page 36
1 142-590S 3PT FERT BOX LID HINGE ASSY RH pre-installed. see page 36
2 168-127D 3/16 X 1 KEY pre-installed
2 800-121C BALL STUD 10MM X 5/16-18 UNC pre-installed
12 802-034C HHCS 1/2-13X1 1/4 GR5 pre-installed
1 802-044C HHCS 1/2-13X4 GR5 pre-installed
4 802-149C RHSNB 3/8-16X3/4 GR5 pre-installed
4 802-282C RHSNB 5/16-18X1 GR5 pre-installed
5 802-387C HFS 5/16-18X3/4 GR5 pre-installed
2 802-425C HHCS 5/16-18X1 1/4 NYL pre-installed
4 803-008C NUT HEX 5/16-18 PLT pre-installed
2 803-011C NUT LOCK 5/16-18 PLT pre-installed
4 803-014C NUT HEX 3/8-16 PLT pre-installed
8 803-020C NUT HEX 1/2-13 PLT pre-installed
1 803-147C NUT HEX NYLOCK 1/2-13 pre-installed
4 803-169C NUT HEX FLG. LOCK 1/2-13 PLT. pre-installed
5 803-199C NUT HEX FLANGE 5/16-18 PLT pre-installed
4 804-009C WASHER LOCK SPRING 5/16 PLT pre-installed
4 804-012C WASHER FLAT 3/8 SAE PLT pre-installed
4 804-013C WASHER LOCK SPRING 3/8 PLT pre-installed
8 804-015C WASHER LOCK SPRING 1/2 PLT pre-installed
4 804-016C WASHER FLAT 1/2 SAE PLT pre-installed
3 804-017C WASHER FLAT 1/2 USS PLT pre-installed
6 804-036C WASHER FLAT 5/16 SAE PLT pre-installed
2 807-106C SPRING .540 O.D.X 1 1/4 X.054W pre-installed
1 808-040C SPKT 40B12 X 3/4 B W/KW&SS pre-installed
1 808-170C SPKT 40B17 X 3/4BORE W/KW&SS pre-installed
1 817-406C IDLER 1 PC 2.38X1.01X1.062 pre-installed
1 817-805C LID LATCH pre-installed
2 822-126C BRG FLG .75ID 2BOLT pre-installed
7 838-160C DECAL 3 COLOR STRIPE 2.50 WIDE pre-installed
1 838-161C DECAL LOGO&GP F/STRIPE 4 X 24 pre-installed
1 890-308C 9 1/4-15 X 70LB GAS SPRING pre-installed
